AC Power Cord > Rubber Insulated Sheathed Flexible Cord > America Rubber Cables > America Rubber Cable SO SOO SOW SOOW S
America-Rubber-Cable-SO-SOO-SOW-SOOW-S

  • America Rubber Cable SO SOO SOW SOOW S

    • UL/CUL and CSA Standard Rubber Cable.

  • Contact Us
Detailed description

Type Conductor Insulation Thickness Jacket Thickness Overall Diameter Min.Cross-sectional area of Conductor
Size No/mm [mm] [mm] [mm] [mm2]

S 18AWG/2C 41/0.160 0.76 1.52 8.60±0.15 0.798
SO 16AWG/2C 65/0.160 0.76 1.52 9.20±0.15 1.27
SOO 14AWG/2C 41/0.254 1.14 2.03 12.5±0.20 2.02
SOW 18AWG/3C 41/0.160 0.76 1.52 9.00±0.15 0.798
SOOW 16AWG/3C 65/0.160 0.76 1.52 9.70±0.15 1.27
  14AWG/3C 41/0.254 1.14 2.03 13.2±0.20 2.02
  18AWG/4C 41/0.160 0.76 1.52 9.70±0.15 0.798
  16AWG/4C 65/0.160 0.76 1.52 10.5±0.20 1.27
  14AWG/4C 41/0.254 1.14 2.03 14.2±0.20 2.02
  18AWG/5C 41/0.160 0.76 2.03 11.5±0.20 0.798
  16AWG/5C 65/0.160 0.76 2.03 12.4±0.20 1.27
  14AWG/5C 41/0.254 1.14 2.41 16.2±0.20 2.02


Other Termination Options:


Click Here
