South Africa Power Cord Standard

South Africa SABS 164-1 Power Supply Cord Set Plug and Socket


Type M is used almost exclusively in South Africa, Swaziland and Lesotho this plug resembles the Indian type D plug, but its pins are much larger. Type M is a 15 amp plug, and it has three round prongs that form a triangle. The central earth pin is 28.6 mm long and has a diameter of 8.7 mm. The 7.1 mm line and neutral pins are 18.6 mm long, on centres spaced 25.4 mm apart. The centre-to-centre distance between the grounding pin and the middle of the imaginary line connecting the two power pins is 28.6 mm.

Contents

1.Plug Guide
2.Power Cords
3.Flexible Cables
4.Certifications
5.References

Plug Guide


South Africa Plug 16A 250V
South Africa Plug 16A 250V
The South African version of the M plug often has insulated sleeves on the pins to prevent accidental contact with a bare connector while the plug is partially inserted. Although type D is used in India, Sri Lanka and Nepal, type M is also used for larger appliances. Some sockets over there can take both type M and type D plugs. Type M is also used in Israel and the United Arab Emirates for heavy appliances such as air-conditioning circuits (in cases where wall-mounted units are plugged in to a dedicated socket) and certain types of washing machines. In the UK, type M is still pretty much the standard plug for theatre installations, despite efforts to move to the international blue- and red-coloured industrial CEE plugs.


Power Cords


South Africa power cord products with SABS certification are manufactured to SABS 164-1, BS546 and IEC standards; designed for South African power supply cord applications,We are producing South Africa power cords in standard configurations and can make any custom version as well.100% of our South African plugs,power cables and electrical sockets are fully molded high quality cords and RoHS / REACH environment compliant as we are China leading South African power cable manufacturer and supplier providing qualified SABS approved plug molded with IEC C7,C5,C13,C15,C19 cord sets. South Africa has, like almost any country, its own set of specific power cords. Below, you will find the power cords we manufacture for South Africa, as well as their specs. The power cords we manufacture for South Africa are also available in other lengths and colours. Our knowledge of the market and our engineering capabilities allow us to continually expand our range of products, including power cords for South Africa. We prefer to make any decisions as to our range in cooperation with our customers. So please do not hesitate to contact us about new products in our ‘South Africa power cords’ category.
Power Supply Cord South African SABS 6A
 Power Supply Cord South African SABS 16A
 Power Supply Cord South Africa Insulation Pin 6A
 Power Supply Cord South Africa Insulation Pin 16A
Power Supply Cord South African SABS 6A Power Supply Cord South African SABS 16A Power Supply Cord South Africa Insulation Pin 6A Power Supply Cord South Africa Insulation Pin 16A


IEC 60320 Connectors


IEC 60320 power cables come in normal and high-temperature variants, as well as various rated currents. The connectors have slightly different shapes to ensure that it is not possible to substitute a cable with a lower temperature or current rating, but that it is possible to use an overrated cable. Cords also have different types of exterior jackets available to accommodate environmental variables such as moisture, temperature, oils, sunlight, flexibility, and heavy wear. For example, a heating appliance may come with a cord designed to withstand accidental contact with heated surfaces.

IEC 60320 C5 Power Receptacle
 IEC 60320 C5 Power Cord
 IEC 60320 C5 Power Cord with Protection Cover
 IEC 60320 C7 Power Cord
IEC 60320 C5 Power Receptacle IEC 60320 C5 Power Cord IEC 60320 C5 Power Cord with Protection Cover IEC 60320 C7 Power Cord
IEC 60320 C7 Power Receptacle
 IEC 60320 C13 Power Cord
 IEC 60320 C13 Power Cord Right Angle
 IEC 60320 C13 Power Cord Custom Made
IEC 60320 C7 Power Receptacle IEC 60320 C13 Power Cord IEC 60320 C13 Power Cord Right Angle IEC 60320 C13 Power Cord Custom Made
IEC 60320 C13 Power Cord Waterproof
 IEC 60320 C14 Power Plug
 IEC 60320 C14 Power Plug Waterproof
 IEC 60320 C14 Power Plug Custom
IEC 60320 C13 Power Cord Waterproof IEC 60320 C14 Power Plug IEC 60320 C14 Power Plug Waterproof IEC 60320 C14 Power Plug Custom
IEC 60320 C14 Power Cord Right Angle
 IEC 60320 C15 Power Cord
 IEC 60320 C15 Power Cord Right Angle
 IEC 60320 C17 Power Connector
IEC 60320 C14 Power Cord Right Angle IEC 60320 C15 Power Cord IEC 60320 C15 Power Cord Right Angle IEC 60320 C17 Power Connector
IEC 60320 C18 Power Plug
 IEC 60320 C19 Power Connector
 IEC 60320 C19 Power Cord Right Angle IEC 60320 C20 Power Cord
IEC 60320 C18 Power Plug IEC 60320 C19 Power Connector IEC 60320 C19 Power Cord Right Angle IEC 60320 C20 Power Cord


Flexible Cables


PVC Insulated Flexible Cord

Cable type Number of cores conductors Section mm2
H03VVH2-F ( Flat) 2 x 0.5-0.75
H03VV-F 2-4 x 0.5-0.75
H05VVH2-F (Flat) 2x 0.75-1.0
H05VV-F 2-5 x 0.75-4.0

Rubber Flexible Cord

Cable type Number of cores conductors Section mm2
H03RT-H 2-3 x 0.75-1.5
H05BB-F 2-4 x 0.75-2.5
H05RN-F 2-3 x 0.75-1.0
H05RR-F 2-5 x 0.75-4.0
H07RN-F 2-5 x 1.0-4.0


Certification

Plugs and socket in South Africa with SABS approved.

South Africa SABS approved


Reference

1.South Africa Plugs and socket outlets test report (PDF) SABS Plugs and socket outlets for household and similar purposes test report.
2.Catalog Europe,South Africa and Other Countries 2102.
