Future Products

Indonesia Power Cord Standard

Indonesia Power Supply Cord Plug Flexible Cable


Indonesia SNI Power plug and flexible power cable.

Contents
1 . Plug Guide
2 . Power Cords
3 . Flexible Cables
4 . Certifications

Plug Guide

Indonesia plugs are same with German types as below.


CEE 7/16 "Europlug" (Type C) Indonesia


The CEE 7/16 standard sheet rated at 2.5 A is unearthed and has two round 4 by 19 mm (0.157 by 0.748 in) pins, which converge slightly towards their free ends. CEE 7/16 has two variants, alternative I is a round plug .Alternative II is a flat version, popularly known as the Europlug. Because it is unpolarised, it can be inserted in either direction into a socket, so line and neutral are connected arbitrarily. The separation and length of the pins allow its safe insertion in CEE 7/1, CEE 7/3 "Schuko", CEE 7/5, and most Israeli, Swiss, Danish and Italian sockets. Most modern UK dedicated shaver sockets designed to accept BS 4573 shaver plugs also accept Europlugs for applications requiring less than 200 mA

There is no socket defined by EN 50075, neither is there a socket in CEE 7 to accept only 4 mm (0.157 in) pins or the profile of a Europlug, however there are examples of sockets on the market which accept only such plugs, sometimes in multiples.

CEE 7/17 unearthed plug Indonesia


CEE 7/17 plug,This is a round plug which conforms to a shape compatible with CEE 7/1, CEE 7/3, and CEE 7/5 sockets. It has two round pins measuring 4.8 by 19 mm (0.189 by 0.748 in). It may be rated at either 10 A or 16 A, and may be used for larger unearthed appliances (and in South Korea for all domestic non-earthed appliances). It is also defined as the Class II plug in Italian standard CEI 23-5. It can be inserted in to Israeli SI 32 with some difficulty. The Soviet GOST 7396 standard includes both the CEE 7/17 and the CEE 7/16 variant II plug。


Indonesia Plug 16A 250V
Indonesia 16A Plug

CEE 7/7 Indonesia


To bridge the differences between German and French standards, the CEE 7/7 plug was developed. It is polarised to prevent the line and neutral connections from being reversed when used with a French CEE 7/5 socket, but allows polarity reversal when inserted into a German CEE 7/3 socket. The plug is rated at 16A.

Power Cord


Indonesia power cord products with SNI certification are manufactured to Sucofindo and IEC standards designed for Indonesian power cord applications,We are producing Indonesia power cords in standard configurations and can make any custom version as well.100% of our Indonesian power cords are fully molded high quality cords and RoHS and REACH compliant as we are China leading Indonesia power cord manufacturer and supplier providing cheapest prices of Indonesia SII approved plug to IEC C7,C5,C13,C15,C19 power supply cords products with good quality.
Indoneisa Power Cord SNI 2.5A JF-01
 Indoneisa Power Cord SNI 16A JF-02
 Indoneisa Power Cord SNI 16A JF-03
Indoneisa Power Cord SNI 2.5A JF-01 Indoneisa Power Cord SNI 16A JF-02 Indoneisa Power Cord SNI 16A JF-03


IEC 60320 Connectors


IEC 60320 power cables come in normal and high-temperature variants, as well as various rated currents. The connectors have slightly different shapes to ensure that it is not possible to substitute a cable with a lower temperature or current rating, but that it is possible to use an overrated cable. Cords also have different types of exterior jackets available to accommodate environmental variables such as moisture, temperature, oils, sunlight, flexibility, and heavy wear. For example, a heating appliance may come with a cord designed to withstand accidental contact with heated surfaces.

IEC 60320 C5 Power Receptacle
 IEC 60320 C5 Power Cord
 IEC 60320 C5 Power Cord with Protection Cover
 IEC 60320 C7 Power Cord
IEC 60320 C5 Power Receptacle IEC 60320 C5 Power Cord IEC 60320 C5 Power Cord with Protection Cover IEC 60320 C7 Power Cord
IEC 60320 C7 Power Receptacle
 IEC 60320 C13 Power Cord
 IEC 60320 C13 Power Cord Right Angle
 IEC 60320 C13 Power Cord Custom Made
IEC 60320 C7 Power Receptacle IEC 60320 C13 Power Cord IEC 60320 C13 Power Cord Right Angle IEC 60320 C13 Power Cord Custom Made
IEC 60320 C13 Power Cord Waterproof
 IEC 60320 C14 Power Plug
 IEC 60320 C14 Power Plug Waterproof
 IEC 60320 C14 Power Plug Custom
IEC 60320 C13 Power Cord Waterproof IEC 60320 C14 Power Plug IEC 60320 C14 Power Plug Waterproof IEC 60320 C14 Power Plug Custom
IEC 60320 C14 Power Cord Right Angle
 IEC 60320 C15 Power Cord
 IEC 60320 C15 Power Cord Right Angle
 IEC 60320 C17 Power Connector
IEC 60320 C14 Power Cord Right Angle IEC 60320 C15 Power Cord IEC 60320 C15 Power Cord Right Angle IEC 60320 C17 Power Connector
IEC 60320 C18 Power Plug
 IEC 60320 C19 Power Connector
 IEC 60320 C19 Power Cord Right Angle IEC 60320 C20 Power Cord
IEC 60320 C18 Power Plug IEC 60320 C19 Power Connector IEC 60320 C19 Power Cord Right Angle IEC 60320 C20 Power Cord


Flexible Cables


PVC Insulated Flexible Cord

Cable type Number of cores conductors Section mm2
H03VVH2-F ( Flat) 2 x 0.5-0.75
H03VV-F 2-4 x 0.5-0.75
H05VVH2-F (Flat) 2x 0.75-1.0
H05VV-F 2-5 x 0.75-4.0

Rubber Flexible Cord

Cable type Number of cores conductors Section mm2
H03RT-H 2-3 x 0.75-1.5
H05BB-F 2-4 x 0.75-2.5
H05RN-F 2-3 x 0.75-1.0
H05RR-F 2-5 x 0.75-4.0
H07RN-F 2-5 x 1.0-4.0

Certification

Plugs and socket in Indonesia with NEW SNI standard.
Indonesia SNI certificated
